Miniature relæ - 24VDC / 5A, 1 x skifte (SPDT)
Varenr:
H58620
EAN:
5705412586207
Specifications:
- Manufacturer: HONGFA RELAY
- Type of relay: Electromagnetic
- Contacts configuration: SPDT
- Rated coil voltage: 24Vdc
- AC contacts rating @R: 5A 250V AC
- DC contacts rating @R: 5A 30Vdc
- Contact current max.: 10A
- Switched voltage: Max. 30Vdc, max. 250V AC
- Relay variant: Subminiature
- Mounting: PCB
- Coil resistance: 1.28 kOhm
- Coil voltage min.: 18Vdc
- Coil voltage max.: 31.2Vdc
- Operate time: 8ms
- Body dimensions: 20.5x15.3x10.2mm
- Release time: 5ms
- Coil power consumption: 450mW
- Operating temperature: -40...70°C
- Contact resistance: 100 mOhm
- Contact material: AgNi
- Terminal pitch: 7.6mm
