VELBUS - Rullegardin kontrolmodul
Varenr:
H23232
EAN:
5410329347680
Egenskaber:
- Can be used til control an electric roll-down shutter, sunblind...
- Suppressed relay contacts
- Manual control on the module
- Controllable by connecting several push buttons in parallel
- Controllable trough VELBUS
- Programmable without PC
- Simple learning process
- Learned push buttons will be saved in case of effekt failure
- Reporting towards the control modules
- 252 possible addresses
- LED indications for:
- UP og DOWN relay output
- UP og DOWN control modes
- Power spænding
- Data reception og forwarding through VELBUS
Tekniske detaljer:
- 4 possible switching times : 15s - 30s - 1min - 2 min
- Relay contacts: 5A/230Vac maks.
- Push button input debounce: 65ms
- Forsyningsspænding: 12VDC
- Strømforbrug: 70mA
- Standard DIN rail housing: 2 modules
- Størrelse: 90 x 36 x 58mm, vægt: 110g
